Painted Steel Strapping

We are a professional manufacturer of painted steel strapping in China. Our products are sold all over the world and have been highly praised by the majority of our cooperative merchants. If you are looking for products such as painted steel strapping, you may wish to contact us. I believe our expertise can satisfy you.

Painted steel strapping is a new type used for strapping cargo packing belt, It has better performance in all aspects than other common steel belts.

Firstly, embodied in the Painted steel strapping won’t appear rusty phenomenon, Painted steel strapping does not like ordinary steel belt packaging rusty spot goods, more environmental protection.

Secondly, Painted steel strapping after cold rolling, shearing, bluing or paint or galvanized, and so on, the finished good elongation, tensile strength, the goods strapping compared strong trust, this is also why Painted steel strapping is more and more popular.

Regular size: 0.3/0.36/0.4/0.5/0.6 * 16mm, 0.7/0.8/0.9*19mm, 0.8*25mm, 0.8/0.9/1.0*32mm, 1.0/1.2*40mm

Advantages

1. We have the best quality control and offer competitive prices.

2. All of our bundled products are handled with patent technology, which includes removing burrs and frays. Our steel strapping is smooth-edged, ensuring safe use.

3. We can produce mini rolls with a weight tolerance of +/- 0.5kg, as well as jumbo rolls with a coil weight of 150kg-400kg.

4. We can also produce super Heavy duty Steel Strapping with an average tensile strength of 950 Mpa and a minimum elongation of 8%.

Technical Parameters

Product Color	Black Painted steel strapping, Green Painted steel strapping, Brown Painted steel strapping, Grey Painted steel strapping, Blue Painted steel strapping
Surface Finish	Painted & waxed
Material	High tensile steel Q195 / Q235 / Q345B / DB460 /
Tensile strength	(Q195)550-700Mpa / (Q235)680-780Mpa / (Q345)780-880Mpa /(DB460)880-980Mpa
Enwind type	Ribbon / oscillated Steel strapping
Elongation	3-6% / 6-8% / 8-12%
Width	9.5, 10.2, 11, 12, 12.7, 15, 16, 17, 17.25, 19, 22, 24, 25, 25.4, 31, 31.75, 32, 40, 45mm (Width tolerance:±0.1mm)
Thickness	0.27-1.5mm (Thickness tolerance: ±0.02mm)
Inner diameter	200 / 300 / 406mm

Steel strapping Size				Strength*		Strap Finish	Coil Winding	Coil Weight
width		gauge
mm	inch	mm	inch	N	lbs			kg	lbs
16	5/8	0.50	0.020	8540	1,920	Painted & Waxed	Mill	47.6	105
16	5/8	0.60	0.023	9790	2,200	Painted & Waxed	Mill	47.6	105
19.0	3/4	0.50	0.020	10230	2,250	Painted & Waxed	Mill	47.6	105
19.0	3/4	0.60	0.023	11740	2,600	Painted & Waxed	Mill	47.6	105
19.0	3/4	0.65	0.025	12450	2,800	Painted & Waxed	Ribbon	47.6	105
19.0	3/4	0.65	0.025	12450	2,800	Painted & Waxed	Mill	34.0	75
19.0	3/4	0.65	0.025	12450	2,800	Zinc	Mill	47.6	105
19.0+	3/4+	0.75	0.029	14900	3,350	Painted & Waxed	Ribbon	47.6	105
19.0+	3/4+	0.75	0.029	15125	3,400	Painted & Waxed	Ribbon	34.0	75
25	1^	0.80	0.031	20700	4,655	Painted & Waxed	Ribbon	50	110
31.75	1-1/4	0.65	0.025	21350	4,800	Painted & Waxed	Ribbon	50	110
31.75	1-1/4+	0.75	0.029	24910	5,600	Painted & Waxed	Ribbon	50	110
31.75	1-1/4+	0.75	0.029	25000	5,600	Zinc	Ribbon	50	110
31.75	1-1/4	0.80	0.031	25132	5,650	Painted & Waxed	Ribbon	50	110
31.75	1-1/4	0.90	0.035	29630	6,660	Painted & Waxed	Ribbon	50	110
31.75	1-1/4^	1.00	0.039	32200	7,239	Painted & Waxed	Ribbon	50	110
31.75	1-1/4	1.12	0.044	37590	8,450	Painted & Waxed	Ribbon	50	110

Applications

Application: packaging and fixing wood, pipelines, cables, steel coils, wires, bricks, non-ferrous metals, etc.

Application field: warehouse storage, logistics transportation, construction sites, automobile manufacturing, shipbuilding, machinery manufacturing, electronic manufacturing and other fields.

Painted steel strapping strapping Manufacturer

Jushuo Packaging focuses on providing high-quality PP strap, PET strap and other plastic packaging products & machines, and excellent service with years’ expertise. Jushuo Packaging provides you with wholesale, customization, OEM & ODM service...

If you have any questions about painted steel strapping, please don't hesitate to contact us at any time. We will provide detailed information and technical support about the features, specifications, solutions and customization options of PP strap, PET strap and other plastic packaging products and machines... Welcome you to visit our factory!
