Large Frame Automatic PP Strap

The Large Frame Automatic PP Strap is engineered for the most demanding industrial packaging applications, specifically designed to operate flawlessly with imported large-frame automatic strapping machines. Built to handle heavy, bulky, or high-density loads, this robust heavy-duty pp strap delivers unmatched stability during high-speed operation, exceptional tensile strength, and a powerful, reliable seal. It is the definitive solution for industries where securing substantial weight and volume is a critical operational requirement.

Extending beyond high-speed consumer packaging, Jushuo Large Frame Automatic PP Strap is engineered for the demands of heavy industry and construction. It provides critical security for steel coils and large-diameter pipes in the metal sector, ensures stable unitization of lumber and panel products in timber processing, and securely bundles oversized concrete pipes and construction beams. Furthermore, it is essential for the safe palletizing and shipment of high-value agricultural and industrial machinery components, proving its unmatched reliability for securing heavy, high-stakes loads.

Main Advantages

● Optimized for Large-Frame Machine Stability
Specifically designed for the wider feed paths and higher tension mechanisms of large-frame machines, ensuring consistent, jam-free feeding even at high speeds and under heavy load conditions.

● Exceptional High Pulling Force
Manufactured to provide superior tensile strength and resistance to stretching, specifically engineered to secure and contain extremely heavy or dense unitized loads without breaking or loosening.

● Robust Construction for Demanding Cycles
Made from a specially formulated, high-toughness polypropylene blend that withstands the stresses of high-tension application and resists abrasion, ensuring long-lasting performance in continuous, heavy-use environments.

● High-Strength Seal for Maximum Security
Delivers a powerful and consistent heat-seal joint that matches the strap’s high tensile strength, creating a complete, fail-safe containment system for valuable or hazardous heavy loads.

Technical Parameters

PRODUCT CODE	DESCRIPTION							PACKAGE
	SURFACE	COLOR	CORE SIZE	NOMINAL WIDTH	NOMINAL THICKNESS	NOMINAL BREAK	LENGTH
JS05035-P	EMBOSSED	C/W	200	5MM	0.35MM	45KG	7000M	WRAFT PAPER
JS05047-P	EMBOSSED	C/W	200	5MM	0.47MM	50MG	7000M	KRAFT PAPER
JS05050-P	EMBOSSED	C/W	200	5MM	0.50MM	55MG	6000M	KRAFT PAPER
JS05060-P	EMBOSSED	C/W	200	5MM	0.60MM	65KG	6000M	KRAFT PAPER
JS09036-PS	SMOOTH	C/Y	200	9MM	0.36MM	110KG	4800M	MRAFT PAPER
JS09050-P	EMBOSSED	W	200	9MM	0.50MM	110KG	4000M	KRAFT PAPER
JS09063-P	EMBOSSED	W/C/B	200	9MM	0.63MM	136KG	4000M	KRAFT PAPER
JS09063B-P	EMBOSSED	W/C/B	406	9MM	0.63MM	136KG	4000M	KRAFT PAPER
JS12050-P	EMBOSSED	C/W	200	12MM	0.50MM	110KG	3000M	KRAFT PAPER
JS12050B-P	EMBOSSED	C/W	406	12MM	0.50MM	110KG	3000M	KRAFT PAPER
JS12063-P	EMBOSSED	C/W	200	12MM	0.63MM	136KG	3000M	KRAFT PAPER
JS12063B-P	EMBOSSED	C/W	406	12MM	0.63MM	136NG	3000M	KRAFT PAPER
JS12063C-P	EMBOSSED	C/W	228	12MM	0.63MM	136KG	3000M	KRAFT PAPER
JS12070-P	EMBOSSED	C/W	200	12MM	0.70MM	160KG	2500M	KRAFT PAPER
JS12080-P	EMBOSSED	C/W	200	12MM	0.80MM	180KG	2000M	KRAFT PAPER
JS15060-P	EMBOSSED	C/W	200	15MM	0.60MM	170KG	2500M	KRAFT PAPER
JS15080-P	EMBOSSED	C/W	200	15MM	0.80MM	200KG	1880M	KRAFT PAPER
JS19080-P	EMBOSSED	C/W	200	19MM	0.80MM	230KG	1500M	KRAFT PAPER

Applications

● Steel & Metal Industry Coil & Pipe Bundling
The standard for securing heavy steel coils, sheets, and large-diameter pipes, providing the necessary strength and stability for safe handling, storage, and transport.

● Timber & Wood Product Palletizing
Ideal for creating stable, high-stability packages of lumber, panel products, and other heavy wood materials on automated lines for the construction and forestry sectors.

● Large-Diameter Pipe & Construction Material Handling
Used to bundle large concrete pipes, construction beams, and other oversized building components, ensuring they remain tightly grouped during movement.

● Heavy Machinery & Industrial Component Packaging
Essential for securing parts of agricultural equipment, industrial machinery, or large vehicle components on pallets for shipment, offering security for high-value items.
